Ingersoll-Rand Up6-5-125/80-230-1 Rotary Screw Air Compressor, Horiz, 5 Hp
This page is affiliate-supported. Prices and availability can change after the last marketplace refresh.
About this product
The Ingersoll-Rand UP6-5-125/80-230-1 is a 5 hp rotary screw air compressor designed for continuous duty. It features a horizontal 80-gallon air tank and delivers a free air flow rate of 14.9 cfm at its maximum operating pressure of 125 psi. This single-phase unit operates on 230V AC, uses synthetic oil lubrication, and has a maximum speed of 3,480 RPM. Its totally enclosed design helps achieve a sound level of 65 dBA.
Our take
This 5 HP Ingersoll-Rand rotary screw compressor with an 80-gallon tank is a robust choice for smaller industrial or serious workshop applications. The 14.9 CFM at 125 psi is quite respectable for a 5 HP unit, and the continuous duty cycle means it can handle demanding tasks without issue. The 65 dBA sound level is a definite plus for a more tolerable work environment. It runs on a single-phase 230V AC, which is more accessible than 3-phase, but still requires a dedicated circuit. The totally enclosed design is a nice touch for noise reduction and protection.
Pros & Cons
Pros
- 5 HP for respectable performance
- 80-gallon horizontal air tank
- 14.9 CFM at 125 psi flow rate
- Single-phase 230V AC input
- Quiet 65 dBA sound level
Cons
- Only 14.9 CFM, lower than some alternatives
- Requires 230V AC dedicated circuit
Specifications
- Brand INGERSOLL-RAND
- Features Rotary Screw Air Compressor, Air Tank Style Horizontal, Output Power 5 hp, Free Air Flow Rate @ Maximum Pressure 14.9 cfm, Maximum Operating Pressure 125 psi, Air Tank Size 80 gal, Phase Single, Input Voltage 230V AC, Air Dryer Included No, Pump Type Rotary Screw, Lubrication Type Synthetic Oil, Current Rating 23.5 A, Frequency 60 Hz, Maximum Speed 3, 480 RPM, Duty Cycle Continuous, Sound Level 65 dBA, Enclosure Type Totally Enclosed
- Model UP6-5-125/80-230-1
- MPN UP6-5-125/80-230-1
- California Prop 65 Warning N
- Country of Origin US
Show all 13 specifications
- Type
- Compressors, Air Tanks & Pneumatic Parts > Air Compressors > Rota
- Weight
- 650.0000
- Length
- 45.000
- Width
- 83.000
- Depth
- 83.000
- Battery Included
- No
- UPC
- 094703217377
